Heatit DIN Transformer 24V
Heatit DIN Transformer 24V
Whitehills
15 Olympic Court
Blackpool FY4 5GU
United Kingdom
Choose options
Transformer for mounting on DIN rail.
Transformer 230VAC to 24VDC 2.5A/60W.
Can be used with Heatit Z-Water2 regulator.
- Transformer
- Input: 230VAC - 50Hz 1.5A Max
- Output: 24VDC / 2.5A / 60W
- High efficiency
- Low ripple & noise
- Adjustable DC voltage output
- Overload protection
- Over voltage protection
- Short Circuit protection
- Isolation Class II
- Mounting on 35mm DIN rail
Technical
-
Voltage:230V 50Hz, 230VAC 50Hz
-
Max load (Watt - resistive load):60
-
Protection grade (IP):IP20
-
Ambient humidity (RH non-condensing %):20-90
-
Ambient temperature range in storage (°C):-40-80
-
Feeding power (Ampere):0.8
-
Total gross effect (W):60
-
Declarations:CE declaration, CE
-
Max connection dimension (mm²):2,5mm²
-
Assembly / mounting location:DIN Rail
-
Width number of DIN-Rail modules:1 module, 3 modules
-
Package size:1
-
Power usage (~Watt):0.5
-
Product height (mm):90
-
Product length (mm):59
-
Product weight (gram):183
-
Product width (mm):51
Manuals
Heatit DIN Transformer 24V Manual
