FIBARO Smart Implant allows to enhance the functionality of wired sensors and other devices by adding Z-Wave network communication.

You can connect binary sensors, analog sensors, DS18B20 temperature sensors or DHT22 humidity and temperature sensor to report their readings to the Z-Wave controller.

It can also control devices by opening/closing output contacts independently of the inputs.

Features

Compatible with any certified Z-Wave or Z-Wave Plus controller.
Supports Z-Wave network Security Modes: S0 with AES-128 encryption and S2 Authenticated with PRNG-based encryption.
Works as a Z-Wave signal repeater.
Allows for connecting sensors:
- 6 DS18B20 sensors,
- 1 DHT sensor,
- 2 2-wire analog sensor,
- 2 3-wire analog sensor,
- 2 binary sensors.
Built-in temperature sensor.

Specifications

Power supply	9-30V DC ±10%
Inputs	2 0-10V or digital inputs 1 serial 1-wire input
Outputs	2 potential-free outputs
Supported digital sensors	6 DS18B20 or 1 DHT22
Maximum current on outputs	150mA
Maximum voltage on outputs	30V DC / 20V AC ±5%
Built-in temperature sensor measurement range	-55°C–126°C (-67°F–259°F)
Operating temperature	0–40°C (32–104°F)
Radio protocol	Z-Wave (500 series chip)
Radio frequency	868.4 or 869.8 MHz EU; 908.4, 908.42 or 916.0 MHz US; 921.4 or 919.8 MHz ANZ; 869.0 MHz RU;
Radio ransmit power	max. 7 dBm (EIRP)
Range	up to 50m (164 ft) outdoors up to 40m (131 ft) indoors (depending on terrain and building structure)
Dimensions (Length x Width x Height)	29 x 18 x 13 mm (1.14” x 0.71” x 0.51”)
Compliance with EU directives	RoHS 2011/65/EU RED 2014/53/EU

Manuals & Documentation

Click here for the FIBARO Smart Implant Manual
