Heatit Z-Relay 25A IP55

Sale price£109.99
Quantity:

Heatit Z-Relay is a multifunction relay with many different uses. The IP 55-classified casing makes the Heatit Z-Relay suitable for outdoor as well as indoor use. The relay can pull up to 16A and 25A. Heatit Z-Relay has 3 inputs that can be used in combination.

Heatit Z-Relay is a multifunctional product and can be used for leakage control, temperature control, water heater control and various outdoor tasks

The relay inputs can be used with different NTC temperature sensors. The relay comes in two different versions, 16A and 25A. Both have OTA, power metering and S2 encryption.


  • Multifunction relay
  • Many different uses
  • 16A or 25A
  • 3 inputs
  • Option of external antenna
  • Can be used with different types of NTC sensors
  • Calibration
  • Associations
  • Firmware Update (OTA)
  • Power metering
  • Multilevel sensor command class
  • Supports encryption mode S0, S2 Authenticated Class, S2 Unauthenticated Class



  • IOT Protocol:Z-Wave - 868.4 MHz (EU)
  • Voltage:230V 50Hz
  • Max load (Watt - resistive load):5750
  • Max current (Ampere):25
  • Own power usage (watt):0.8
  • Max installation temperature (°C):40
  • Min installation temperature (°C):5
  •
