Simply the 'brains' for your smart home. The FIBARO Home Center 3 connects all your devices together and allows their operation to be programmed and controlled remotely via the dedicated FIBARO App from anywhere in the world.
FIBARO Home Center 3 is the core element of the FIBARO System.
It enables the integration of smart home devices into a single system to provide convenient control and a powerful automation platform. The gateway is now even more secure, reliable, and versatile.
It is super easy to set up and configure your FIBARO Home Center 3 but if you prefer some help or simply want to save time then why not select our Pre-Configuration Service which configures your FIBARO Home Center 3 and any smart devices you purchase from us so that you simply need to install them and away you go. You must order your FIBARO Home Center 3, smart devices and our Pre-Configuration Service at the same time.
- Provides a reliable foundation for FIBARO System.
Capable of controlling all FIBARO and other compatible devices using the following radio standards:
- Z-Wave (500 series)
- Wi-Fi – 2.4 GHz and 5 GHz (802.11 b/g/n/a/ac)
- Nice FLOR, OPERA and PLN2+
- No Internet cable required, works also on Wi-Fi
- Modern interface designed for ease of use
- Enhanced and convenient scene editor
- Support for more advanced apps and drivers
- May be used with all devices certified with the Z-Wave Plus certificate and should be compatible with such devices produced by other manufacturers
|CPU||Quad-core Arm Cortex A53 (1.2GHz)|
|RAM||RAM 2GB LPDDR3|
|Flash memory||8GB eMMC|
|Power supply||12V DC (adapter included)|
|Operating humidity||max. 75% relative humidity (non-condensing)|
|Network interface||10/100 (Base-T) Ethernet via RJ45 connector|
|Power connector||barrel connector 5.5mm x 2.5mm (female)|
|Protocol||Radio frequency band||Max. transmitting power|
|AU, NZ, CL||920-925Mhz||+5dBm|
|AU, NZ, CL, BR||433.05-434.04Mhz||+14dBm|
Click here for the Home Center 3 Quick Start Guide
