Unifi Dream Machine Special Edition
Unifi Dream Machine Special Edition
Unifi Dream Machine Special Edition
Unifi Dream Machine Special Edition
Unifi Dream Machine Special Edition
Unifi Dream Machine Special Edition

Ubiquiti

Unifi Dream Machine Special Edition

Sale price£599.99
Sold out
Pickup currently unavailable at Whitehills

Unifi Dream Machine Special Edition

Whitehills

Pickup currently unavailable

6 Thompson Road
Whitehills Business Park
Blackpool FY4 5QF
United Kingdom

+441704325125
Description

All-in-one router and security gateway with an integrated PoE switch and network video recorder.

The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).

Features
  • 1.7 GHz quad-core processor
  • Dual WAN ports (10G SFP+ and 2.5GbE RJ45)
  • (8) GbE RJ45 ports, including (6) PoE and (2) PoE+ LAN ports
  • (1) 10G SFP+ LAN port
  • (1) 1.3" LCM color touchscreen for at-a-glance network monitoring
  • Customizable internet threat filtration and traffic identification for enhanced network security
  • Quick, Bluetooth-powered setup via the UniFi Network web application or mobile app
  • 1U-sized, rack-mountable device
  • Integrated security gateway and UniFi Protect-ready NVR that supports compatible 3.5" HDDs
  • 128 GB integrated storage for full UniFi OS Application experience
Specifications
Processor Quad-Core ARM® Cortex®-A57 at 1.7 GHz
System memory 4 GB DDR4
On-board storage 16 GB eMMC
Integrated 128 GB SSD
IDS/IPS throughput 3.5 Gbps*
*Measured with iPerf3
Max. power consumption (excluding PoE output) 50W
Power method (1) Universal AC input, 100-240VAC, 4.4A
Max, 50/60 Hz (1) USP-RPS DC input, 52VDC, 3.94A
Power supply AC/DC, Internal, 240W
Supported voltage range 100 to 240VAC
Management interfaces Ethernet
Bluetooth
Networking interfaces (1) WAN: 2.5 GbE RJ45 port
(8) LAN: 1 GbE RJ45 ports
SFP+ interfaces (1) WAN: 10G SFP+
(1) LAN: 10G SFP+
PoE interfaces (2) PoE+ (pair A 1, 2+; 3, 6-)
(6) PoE (pair A 1, 2+; 3, 6-)
Max. PoE wattage per port by PSE PoE 15.4W
Max. PoE wattage per port by PSE PoE+ 30W
Voltage range PoE mode 44 to 57V
Voltage range PoE mode 50 to 57V
ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV
LCM display (1) 1.3" touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: firmware upgrading
Button Factory reset
Operating temperature -10 to 40° C (14 to 104° F)
Operating humidity 5 - 95% noncondensing
Certifications

CE, FCC, IC

Manuals

Unifi Dream Machine Manual
